Pockets XXI - Single Welt Pockets


Today we are making a bound welt pocket with a single lip. This method is actually a sort of a shortcut because we are using a single piece of fabric for the facing, lining and lips. It is convenient but it is also limiting in that you are forced to have the same fabric for the outer, decorative part of the pocket (the lips) as the lining (which we usually prefer to be lightweight and undecorative). In a later post, we will demonstrate the un-shortcut method which allows more flexibility in fabric choice.

You will need
  • the main garment fabric
  • interfacing for the pocket opening, which I omitted for simplicity
  • a long piece of fabric for the lining/facing/lips. This piece of fabric must be at least twice as long as the desired depth of your pocket pouch. Here's a simple formula for the length of this piece:

Length = 2 x (final depth of pocket pouch + width of welt opening) + seam allowance.

All will be clear in the later steps.

Because this is the second time I am making the basic welt opening, I am going to omit a lot of the explanations. For more detailed instructions and photos on making the welt opening, see the earlier post
here.


Step 1
Mark on the right side of your garment fabric, the position of the welt opening. Transfer the lines to the wrong side of the garment fabric. I use pins to help mark the positions of the corners.



Step 2
Place your lining/facing/lips fabric piece (polka dotted in this tutorial) over the pocket opening, so that
  • the right sides of the garment and the lining/facing/lips fabric are touching
  • its top edge is about 1" above the top edge of the pocket opening
  • it is centered sideways over the pocket opening.
I am using a piece that is a little over 9" long. It will be folded in half later to make the pocket pouch and the lip. Flip to the wrong side of the garment fabric and sew the top and bottom edges of the welt opening.


Remember to make them exactly the same length.


Step 3
Cut open the welt.



and turn the lining/facing/lips fabric piece right side out through the opening.




Usually this is when you sew down the little triangles at the sides to close the shorter edges of the welt opening. But I am delaying that step for now.




Step 4

Flip to the wrong side of the garment - here is the welt opening seen from the back., with the polka dotted fabric being the
facing.



Step 5
Fold up the entire lining/facing/lips piece




Step 6

and fold it down again, so that its upper fold is at the level of the top edge of the welt opening. You've just made the single
lip - and the polka dotted fabric is now the facing AND the lip. You might need to fiddle about with the fold to make sure the lip exactly covers the welt opening. If your fold is too low, there will be a gap at the top. If your fold is too high, you will have scrunched up fabric at the upper corners.



Step 7

Carefully baste the lip in place to close the welt opening.



Step 8

Now fold back the garment fabric to expose the little triangles at the sides of the welt opening, and sew them down onto the folded facing/lip fabric piece.




Step 9
You may stitch-in-the-ditch along the bottom edge of the welt opening if you like. Or top-stitch around the entire welt opening if this is a more casual garment. Neither is necessary, really.

I added a buttonhole in the middle of the lip instead.



Step 10

Flip to the wrong side of the garment, and fold up the fabric and pin in place. Now the polka dotted fabric is the
facing, the lip AND the lining. Three-in-one! If you hadn't added the buttonhole-and-button, you can now sew up the top edge and two sides of this lining/facing pouch to complete the pocket. But we're going to delay that till Step 12 and sew the button on first.



Step 11

Cut open the buttonhole and mark the position of the button on the lining behind it.




Step 12

Unpin the lining, sew the button in place, and then fold it up and re-pin in place as in Step 10.
Now sew around the edges of the lining/facing to make the pocket pouch.




This is the completed single bound welt pocket!



Here's the same welt pocket, but slanted at an angle on a dress:

It was top-stitched all around the welt opening.



Next: Same thing, but with two lips.
